Zigbee Human Presence Sensor
- Adopts microwave radar technology to sensitively detect human presence;
- 24GHz millimeter wave radar sensing module;
- Supports detection of multiple states of activity, rest, sleep, and unoccupied;
- The product has a built-in light sensor;
- Ceiling mounted
Netplus Zigbee human presence sensor utilizes millimeter wave Doppler radar, detecting human movement and static presence.
With human movement Doppler parameters and human physiological parameters synchronized sensing technology for wireless perception of human status in the area, it reports the wireless signal to the gateway to activate smart scene linkage (not affected by temperature, humidity, noise, airflow, dust, light, etc.); suitable for nursing home, hotel, office, hopsital, etc.
Product Technical Data
Basic Information |
|
| Product Type | Smart Sensor |
| Article | Zigbee Human Presence Sensor |
| Artcle No. | SH-Zigbee-HPS |
| Rated Voltage | AC100-240V 50/60Hz |
| Detection Type | 24GHz millimeter wave Doppler radar |
| Detecting Range | movement detection: 6m x 8m |
| static detection: 4m x 6m | |
| Luminous Range | 0-2000 lux |
| Management App | SmartLife or TuySmart App |
Connectivity |
|
| Protocol | ZigBee 3.0 |
| Wireless Standard | IEEE 802.15.4 b/g/n |
| Signal Range | 100 meters (open field) |
| Security Module | WPA / WPA2 |
| Encryption Type | WEP / TKIP / AES |
| Operating Systems | Android & iOS |
Appearance |
|
| Diameter | 65 mm |
| Depth | 24 mm |
| Colour | White |
| Material | ABS & PC |
| Mounting Type | Ceiling mount |
Working Environment |
|
| Operation Temp. | -10ºC ~ +55ºC |
| Case Temp. | Tc: +40ºC (Max.) |
| Working Humidity | 10% – 80% RH, non-condensing |
| IP Rating | IP20 |
Packing List |
|
| 1 x Zigbee human presence sensor | |
| 1 x user manual | |
